Operating your Line 6 gear can be done by using the Line 6 floorboards.

That is one way of doing it, however Line 6 gear cannot only be operated with the Line 6's FBV floorboards, but also (via MIDI / sysex) with other brands floorboards. To help those along that have other brands of floorboards here's some help on how to get it working.

Please Note

1) The Line 6 gear and Line 6 FBV floorboards are designed to work together

2) Different brand floorboards could be designed for different purposes, however you can use them to work with Line 6 gear.

3) This page and info are in no way affiliated with Line 6. All other product names used in this website are trademarks of their respective owners, which are in no way associated or affiliated with Line 6 or Vettaville. These trademarks of other manufacturers are used solely to identify the products of those manufacturers.

4) These page(s) content is made by and with courtesy of Daniel Lemoine (a.k.a. TigerBill ) a Channel 6 forum member.

5) All changes made, could trigger malfunction of your gear, and could void your warranty, check your manuals before continuing.

FCB 1010 Files info

This Section gives you the possibillity to use a Behringer FCB 1010 floorpedal with the following Line 6 gear:

HD147
Flextone III
Flextone II
POD xt V2.0
POD xt V1.xx
POD 2.0

At the present time there also included a Flextone III Tuning Wizard, also made by Daniel Lemoine, scroll down to reach the different paragraph(s)

FCB files

General purpose

FCB1010_programming.txt

6 KB 03/22/2004

How to's help File for programming the FCB1010:

Patches, toggles, parameters editing, etc...

Source and courtesy of: Daniel Lemoine

FCB 1010 with HD147 or Flextone III

This Section gives you the possibillity to use a Behringer FCB 1010 floorpedal with a Line 6 Flextone III, currently test are done to see if the same files could be used for HD 147, when clear on that we'll post so.

Sysex files for FCB 1010 with Flextone III and HD 147

FBV_enhanced.syx FBV_Enhanced.txt	3 KB 03/08/2004 2 KB 03/08/2004	An emulation of the FBV Shortboard with some tone editing features on #0 bank ( A.I.R. II settings ) Help file for the FBV shortboard emulation
FBV_enhanced_RevD.syx	3 KB 03/19/2004	Same as the original, but Min Vol pedal to keep audible sound with pedal at Min
FBV_enhanced_RevE.syx	3 KB 03/23/2004	Same as the original, but Min & Max defined for the Vol pedal ( 30% to 70% overall power)
FBV_6x6.syx FBV_6x6.txt	3 KB 03/26/2004 5 KB 03/26/2004	FCB with 6 banks x 6 tones and Enhanced Editing in 3 more banks (bank #7 unused) Help file for FBV-6x6
FBV_6x6_Cabs.syx FBV_6x6_Rvb.syx FBV_6x6_Rv-cab.txt	3 KB 03/30/2004 3 KB 03/30/2004 6 KB 03/30/2004	Same as FBV_6x6 plus Cabs on bank#7 Same as FBV_6x6 plus Reverbs on bank#7 Help file for FBV 6 x6 w /Cabs or Revb
Studio_Deep_Edit_RevC.syx Studio_Deep_Edit_revC.txt	3 KB 03/08/2004 7 KB 03/08/2004	A studio tone Editor. All parameters are accessible.. Full options (let use the FCB1010 instead of the Line6 Edit software) Help file for the Deep editor
Stage_Enhanced.syx Stage_enhanced.txt	3 KB 03/08/2004 6 KB 03/08/2004	A middle version between the FBV_Enhanced emulation & the Studio ( 4 banks x 9 tones and enhanced editing features in 6 banks ) Help file for the Stage enhanced

Source and courtesy of: Daniel Lemoine

Tuner Wizard for Flextone III

Here a small application to adjust your Tuner in Flextone III, note this in not a Line 6 application but made by Daniel Lemoine.

The Tuner Wizard is self-explanatory, just open expand the compressed file and run the application with your Flextone and Midi in & out connected. Here's a screenshot

click here to download the Flextone III Tuner Wizard software

Source and courtesy of: Daniel Lemoine

FCB 1010 to work with POD xt Version 2.0

This Section gives you the possibillity to use a Behringer FCB 1010 floorpedal with a Line 6 POD Xt Version 2.0

POD Xt SysEx files

POD Xt 8X8V2.syx

POD Xt 8X8V2.txt

3 KB 29/07/2004

3 KB 26/05/2004

8 banks of 8 patches ( FCB banks #0 to #9 ). The #0 is as described (AIR, Tuner and Effects controls), but in #9, effects controls are replaced with the new parametric EQ controls ( pedals #6 to #10) see help file

Odd POD banks on lower row pedals. Even POD banks on upper ones ( STOMP toggle on each pedal 1st press: Off 2nd: On)

AIR, Comp, MOD, Delay, Reverb, Gate and Tuner controls in banks #0 & #9

Help file for the POD Xt SysEx files

Source and courtesy of: Daniel Lemoine

FCB 1010 to work with POD xt Version 1.xx

This Section gives you the possibillity to use a Behringer FCB 1010 floorpedal with a Line 6 POD Xt Version 1.xx

POD Xt SysEx files

POD Xt 8X8.syx

POD Xt 8X8 Mix.syx

POD Xt 8X8.txt

3 KB 26/05/2004

8 banks of 8 patches ( FCB banks #1 to #8 ). Odd POD banks on lower row pedals. Even POD banks on upper ones ( STOMP toggle on each pedal 1st press: Off 2nd: On)

AIR, Comp, MOD, Delay, Reverb, Gate and Tuner controls in banks #0 & #9

Same as the previous, but lower row pedals with STOMP On / Off

Help file for the POD Xt SysEx files

Source and courtesy of: Daniel Lemoine

FCB 1010 to work with Flextone II or POD 2.0

This Section gives you the possibillity to use a Behringer FCB 1010 floorpedal with a Line 6 Flextone II and POD 2.0

Flextone II & POD 2.0 SysEx files

Floorboard enhanced.syx

Floorboard Rvb ctl.syx

Floorboard Enhanced.txt

3 KB 10/04/2004

2 KB 17/04/2004

An emulation of the Floorboard with cabs selection and AIR control on #0 bank ( no reverb control ).

Drive boost on each patch ( 1st press: Off 2nd: On )

Same as the previous, but with Reverb settings on patches #5 instead of Tap tempo

Help file for the Floorboard emulation

Source and courtesy of: Daniel Lemoine
